RAK WisMesh Tag

The WisMesh Tag is a compact Meshtastic device designed for portable location tracking and mesh messaging. With a 1000mAh battery and IP66 weather resistance, it is built for rugged outdoor use.

Specifications

• MCU
  • nRF52840
    • Bluetooth BLE 5.0
    • Very low power consumption
• LoRa Transceiver:
  • SX1262
• Frequency Options:
  • 868-923 MHz
• GNSS Module
  • AT6558R
• Battery Capacity
  • Rechargeable lithium battery, 1000mAh
• Charging
  • USB magnetic charging cable

Features

• Integrated button for reset and boot mode functionality.
• Integrated acceleration sensor based on ST LIS2DH.
• Four pogo pins for USB, DFU, serial logging, and charging.
• IP66 rated, waterproof and durable for various environments.

Resources

• Firmware file: firmware-rak_wismeshtag-X.X.X.xxxxxxx.uf2
• Further information on the WisMesh Tag can be found on the RAK Documentation Center.
