ThinkNode Series

The ThinkNode Series, designed by Elecrow and powered by Meshtastic, offers a set of compact and dependable devices built for off-grid communication and mesh networking. Designed for portability, long battery life, and reliable wireless performance, they are well-suited for outdoor and remote use.

ThinkNode M1

ThinkNode M1

The ThinkNode M1 is a compact Meshtastic device featuring an nRF52840 MCU, SX1262 LoRa transceiver, built-in GPS, and a 1.54" e-ink display. It includes a 1200 mAh rechargeable battery, and comes pre-installed with Meshtastic with an optional durable enclosure.

Specifications

• MCU:
  • nRF52840
    • Bluetooth 5.0
• LoRa Transceiver:
  • Semtech SX1262
• Frequency Options:
  • US (902.0Mhz to 928.0Mhz)
  • EU_868
• Navigation Module:
  • L76K
• Antenna:
  • RP-SMA
• Connectors:
  • USB-C

Features

• Meshtastic pre-installed.
• 1.54" e-ink display.
• 1200 mAh rechargeable battery.
• Integrated buzzer.
• Rotary encoder for backlight control.

Resources

• Firmware file: firmware-thinknode_m1-X.X.X.xxxxxxx.uf2
• Purchase Links:
  • International
    • Official Store
• Elecrow's Official Wiki

ThinkNode M2

ThinkNode M2

The ThinkNode M2 is a compact Meshtastic device featuring an ESP32-S3 MCU, SX1262 LoRa transceiver, and a 1.3" OLED display. It includes a 1000 mAh rechargeable battery, and comes pre-installed with Meshtastic with an optional durable enclosure.

Specifications

• MCU:
  • ESP32-S3
    • 2.4GHz Wi-Fi b/g/n
    • Bluetooth 4.2
• LoRa Transceiver:
  • Semtech SX1262
• Frequency Options:
  • US (902.0Mhz to 928.0Mhz)
  • EU_868
• Antenna:
  • U.FL/IPEX antenna connector for LoRa.
• Connectors:
  • USB-C

Features

• Meshtastic pre-installed.
• 1.3" OLED display.
• 1000 mAh rechargeable battery.
• Integrated buzzer.

Resources

• Firmware file: firmware-thinknode_m2-X.X.X.xxxxxxx.bin
• Purchase Links:
  • International
    • Official Store
• Elecrow's Official Wiki

ThinkNode M3

ThinkNode M3

The ThinkNode M2 is a compact Meshtastic device featuring an ESP32-S3 MCU, SX1262 LoRa transceiver, and a 1.3" OLED display. It includes a 1000 mAh rechargeable battery, and comes pre-installed with Meshtastic with an optional durable enclosure.

Specifications

• MCU
  • nRF52840 (Bluetooth 5 LE)
• LoRa Transceiver
  • Semtech LR1110
• Frequency options
  • 915 MHz
  • 868 MHz
• GNSS Module
  • ATGM336H-5NR32
• Battery Capacity
  • Rechargeable lithium battery, 770 mAh
• Charging
  • USB magnetic charging cable

Features

• Compact, pocket-sized design.
• Integrated Temperature, Humidity, and Accelerometer sensors.
• Four pogo pins for USB, DFU, serial logging, and charging.
• IP66 rated, waterproof and durable for various environments.

Resources

• Firmware file: firmware-thinknode_m3-X.X.X.xxxxxxx.uf2
• Purchase Links:
  • International
    • Official Store
• Elecrow's Official Wiki
